My lab's instruments

Last update: 5/05/2015

All the material present in this page, if not otherwise specified, is covered by the Creative Commons Attribution-ShareAlike license
Creative Commons License

HP 54504A Digital scope

Characteristics
  • Channels: 2
  • Real-Time Bandwidth: 50MHz
  • Repetitive Bandwidth: 400MHz
  • Real-Time Rise time: 7ns
  • Repetitive Rise time: 875ps
  • Real-Time Sample rate: 200Msa/s
  • Repetitive Sample rate: 25Msa/s
  • Vertical sensitivity: 1mV/div
  • Vertical resolution: 8bit
  • Real-time horizontal resolution: 5ns
  • Repetitive horizontal resolution: 50ps
  • Memory: 501 / 2001 points
  • Input R: 1MΩ, 50Ω


    • Hitachi V-152F Analog scope

    Characteristics
  • Channels: 2
  • Bandwidth: 15MHz
  • Rise time: 24ns
  • Vertical sensitivity: 1mV/div
  • Vertical resolution: 5mV/div - 5V/div
  • Input R: 1MΩ


    • Goldstar FC-7011 Frequency counter

    Characteristics
  • Bandwidth: 100MHz
  • Resolution: 8 digits
  • Gate time: 0.01s, 0.1s, 1s, 10s


    • Nuova Elettronica LX.5048 Frequency counter

    Characteristics
  • Bandwidth: 10MHz
  • Resolution: 5 digits
  • Gate time: 0.1s, 1s, 10s


    • ITT doc 2000 desk multimeter

    Characteristics
  • DC Voltage: 2V, 20V, 200V, 1000V
  • AC Voltage: 2V, 20V, 200V, 1000V
  • DC Current: 2mA, 20mA, 200mA, 2A
  • AC Current: 2mA, 20mA, 200mA, 2A
  • Resistance: 2Ω, 20Ω, 200Ω, 2KΩ, 20MΩ
  • Resolution: 3.5 digits


    • Saleae Logic16 Logic analyzer
    (many thanks to Serge Defever for this gift)

    Characteristics
  • Channels: 16
  • Sample rate: 100MHz, 80MHz, 50MHz, 40Mhz, 32MHz, 25MHz, 16MHz, 12.5MHz, 10MHz, 8MHz, 6MHz, 5MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz
  • Supported voltages: 1.8V, 2.0V, 2.5V, 3.3V, 5V
  • Sample depth.: up to 10Gsa
  • Connections: 2x 8ch + GND, USB
  • Note: compatible with Windows (XP or newer), Mac OS X (10.4 or newer), Linux


    • Metex MS-9150 Multi function set

    Characteristics
      Multimeter
    • DC Voltage: 400mV, 4V, 40V, 400V, 1000V
    • AC Voltage: 400mV, 4V, 40V, 400V, 750V
    • DC Current: 400μA, 4mA, 40mA, 400mA, 20A
    • AC Current: 400μA, 4mA, 40mA, 400mA, 20A
    • Resistance: 400Ω, 4KΩ, 40KΩ, 400KΩ, 4MΩ, 40MΩ
    • Capacity: 4nF, 40nF, 400nF, 4μF, 40μF, 400μF
    • Diode: 2V
    • Resolution: 3.5 digits
      Frequency counter
    • Resolution: 8 Digits
    • Channel A bandwidth: 100Hz
    • Channel B bandwidth: 100Hz
    • Channel C bandwidth: 1.3GHz
    • Gate time: 0.1s, 1s, 10s
      Function generator
    • Waveforms: Sine, Square, Triangle
    • Frequency : 1Hz - 2MHz
    • Output voltage: 2Vpp, 20Vpp(Unload), 200mVpp, 2Vpp(-20dB)
    • VCF: 0V, 10V
    • Output R: 50Ω, 600Ω
      Power supply
    • Output voltage: adjustable up to 30V
    • Output current: adjustable up to 2A
    • Stability: 1mV ripple, 5mV load
    • Fixed output voltage: 5V 2A, 2mV ripple, 5mV load
    • Fixed output voltage: 15V 2A 2mV ripple, 70mV load


    JBC CD-2BC soldering station

    Characteristics
  • Power: 130W
  • Temperature: 90-450 °C


    • Zhongdi ZD-915 desoldering station

    Characteristics
  • Power: 80W
  • Temperature: 160-480 °C


    • GBC KDM-400CF multimeter

    Characteristics
  • DC Voltage: 200mV, 2V, 20V, 200V, 1000V
  • AC Voltage: 2V, 20V, 200V, 750V
  • DC Current: 2mA, 20mA, 200mA, 10A
  • AC Current: 2mA, 20mA, 200mA, 10A
  • Resistance: 200Ω, 2KΩ, 20KΩ, 200KΩ, 2MΩ, 20MΩ, 200MΩ
  • Capacity: 2nF, 20nF, 200nF, 2μF, 100μF
  • Temperature: -20°C - 1000°C
  • Diode: 2V
  • Frequency: 20KHz
  • hFE
  • Resolution: 3.5 digits


    • GBC MS-2002 Current clamp

    Characteristics
  • DC Voltage: 600V
  • AC Voltage: 600V
  • AC Current: 2A, 20A, 200A
  • Resistance: 2KΩ


    • HY3005 Desk power supply

    Characteristics
  • Output voltage: adjustable up to 30V
  • Output current: adjustable up to 5A
  • Stability: 1mV ripple
